Piping & Tubing System Package
Vacuum pump unit
This product is equipment designed to create a vacuum state by expelling gas from a container. Unlike conventional vacuum systems that use rotary pumps, this equipment significantly reduces the time required to achieve a high vacuum state (5×10⁻⁴ torr), thereby shortening operation times.
| No. | Specification | Description |
|---|---|---|
| 1 | DRY PUMP(DV800) | 380V, 3-phase, 19.6 kW, 5×10⁻³ torr |
| 2 | DIFFUSION PUMP | 380V, 3-phase, 10 kW, 5×10-⁴torr |
| 3 | CHILLER | 220V, 3-phase, 4.56 kW, 5HP |
FGSS (Fuel Gas Supply System)
Vaporizer & Glycol Water Skid
LNG LP (Liquefied Natural Gas Low Pressure) Vaporizer Skid is an important equipment used in the natural gas industry, specifically to convert liquefied natural gas (LNG) back into a gaseous state for distribution and consumption. The primary purpose of a glycol-water system in LNG facilities is to prevent hydrate formation, maintain temperature control, and ensure safe transportation and processing of LNG.
Bunkering Station
Bunkering Skid on LNG-powered vessels refers to the system that supplies liquefied natural gas (LNG) as fuel to the vessel. Our Bunkering Skid is equipped with an ultra-low temperature transfer system.
High Pressure Buffer Tank Skid
An LNG HP (High Pressure) Buffer Tank SKID is an essential component used in the storage and management of liquefied natural gas (LNG) in high-pressure systems. It serves as a buffer or intermediary storage unit that helps regulate pressure and flow within the LNG infrastructure, particularly in facilities where LNG is being stored, transported, or regasified.
WTS (Water Treatment System)
EGR (Exhaust Gas Recirculation) WTS Unit
In the EGR system, the discharged wastewater is purified through a centrifuge and filter, and the contamination level of the water is measured to meet environmental regulations before being discharged overboard.
WTS Pump Unit
A device that sends the water stored in the EGR Drain Tank to the EGR WTS unit.
BUFFER TANK WITH SUPPLY UNIT
A tank is used to store excess water from the EGR system, where a neutralizing agent (NaOH) is added to regulate the pH of the acidified water. This process controls both the quantity and quality of the water used in the EGR system.
Vacuum Pumping System Package
Custom made 'Vacuum Pumping System Package' is provided.
Others
High Pressure Valve
| Material | Stainless Steel 304 & 316L |
| Type | Ball valve / Check valve / Needle valve and Shuttle valve |
| We provide proper working pressure, temperature and size as customers’ needs and applications. | |
High Pressure Hose
| Working Pressure | 40~630Bar(g) |
| Nominal size of House | 1/4” ~ 4” |
| We provide different materials, pressure levels, and connection forms of high pressure hose. | |
Pipe in Stock or Order Based
| Stainless Steel | 904L, S31254(6Mo), 317L, 316(+2.5%Mo), 304L |
| Duplex | S32750, S31803(S32205) |
| Nickel Alloys | 20, 200, 400, 600, 625, 825, C276 |
| Copper Alloys | CuNi70/30, CuNi90/10, Brass, Bronze, Al-Br |
Fitting
| Stainless Steel | 316L(+2.5%Mo), 304L |
| Duplex | S32750, S31803(S32205) |
| Copper Alloys | CuNi70/30, CuNi90/10, Brass, Bronze, Al-Br |
| We provide different types as for customers’ needs and applications. | |
